Specification	Detail
Model	9GL-5.0/5.6
Cutting Width	5,000 mm
Raking Width	5,600 mm
Power Required	30–60 kW / 40–80 HP
Working Speed	8–12 km/h
Operation	Single-pass mow and rake
Suitable Terrain	Flat to moderate slope
Machine Weight	Approx. 1,100 kg

Mow and Rake in a Single Pass: Halving Your Field Operations

The Ever-Power 9GL-5.0/5.6 Mower-Rake Combination does something that two separate machines cannot: it mows and rakes in a single tractor pass. With a 5,000 mm cutting width and a 5,600 mm raking width operating simultaneously, the 9GL-5.0/5.6 produces a baler-ready windrow immediately behind the cutting action — eliminating the additional field pass, fuel cost, soil compaction, and time delay that separate mowing and raking operations create.

For large hay operations where field time is the limiting factor during peak harvest windows, the efficiency gain from single-pass harvesting is substantial. Fewer passes mean less soil compaction in wet conditions, less fuel consumption per hectare, and faster progression through the crop before conditions change. The 9GL-5.0/5.6 is designed specifically for the flat to moderately sloped terrain of the Buenos Aires Province pampas and similar agricultural landscapes globally.

5.0m Cut, 5.6m Rake: Understanding the Width Relationship

The 9GL-5.0/5.6 cuts a 5,000 mm swath and simultaneously rakes it into a 5,600 mm consolidated windrow. The raking width being wider than the cutting width is deliberate: the raking mechanism gathers and consolidates the cut material laterally, producing a narrower, higher-density windrow than the original cut swath. This windrow consolidation is important for baler efficiency — a concentrated windrow feeds more consistently and with less variation in flow than a wide, flat swath.

The resulting windrow is positioned centrally between the tractor wheel tracks, ready for the baler on the next pass. No repositioning of the windrow is required, and the baler pick-up can operate at consistent forward speed without the variable feeding that comes from inconsistently formed windrows.

Flat Terrain Performance

The 9GL-5.0/5.6 is optimised for flat to moderately sloped terrain, which describes the majority of the pampas region and similar flat agricultural zones globally. On flat terrain, the combination machine achieves maximum efficiency: the cutting and raking systems operate at their designed geometry, and the windrow formation is consistent and predictable for the baler following behind.

On moderate slopes up to approximately 15 degrees, the machine continues to function effectively, though windrow formation may show minor variation with the slope direction. Steep or irregular terrain that creates significant side-slope operation is not recommended for the 9GL-5.0/5.6 — in those conditions, the separate 9GQY-3.2 mower conditioner and appropriate rake would be more suitable.

Pairing with Round Balers

The 9GL-5.0/5.6 is designed to work as the front end of a complete forage harvesting system. Its 5-metre coverage rate produces windrow volumes appropriate for a single large round baler — such as the S9000 Pro or S9000 Classic — following at a comfortable interval. The consolidated windrow format is optimised for the 2,240 mm pick-up width of the S9000 series, ensuring complete windrow collection without the pick-up needing to deviate from a straight line to gather material.

For operations that have already invested in the S9000 series, adding the 9GL-5.0/5.6 completes a two-machine system that covers mowing, raking, and baling in the most time-efficient format available. A single tractor on the 9GL-5.0/5.6 can comfortably keep ahead of one round baler operating at standard output, allowing both machines to work continuously without waiting for the other.

Frequently Asked Questions

Can the 9GL-5.0/5.6 handle lucerne and clover, or just grasses?

The reciprocating cutting system handles grasses, lucerne, clover, and most mixed pasture species effectively. The machine is not recommended for very stemmy or thick-stalked crops that may overwhelm the raking mechanism.

What is the effective area coverage rate?

At 8–12 km/h operating speed with a 5,000 mm cutting width, the 9GL-5.0/5.6 covers approximately 4–6 hectares per hour under normal conditions.

Is after-sales support available locally?

Yes. Ever-Power Forage Baler S.A. in Buenos Aires maintains spare parts inventory and technical support. Email [email protected] for service enquiries.

Manufacturer Credentials: Why Ever‑Power

Ever‑Power Forage Baler S.A. is the Argentine entity of an ISO 9001:2015‑certified manufacturer holding over 100 registered technology patents and National High‑Tech Enterprise recognition (Certificate GR202315000192). Two consecutive years of market leadership in the integrated mower-rake category, AAA Credit Enterprise rating, and the AGMA Best Innovation Award 2023 provide independently verified performance and quality credentials. All certifications are available on request for buyer verification.

Our 32,000 m² production facility operates two dedicated production lines producing over 2,000 units annually. CNC laser cutting, robotic welding, and electrostatic coating are standard production processes on every unit. The 9GL-5.0/5.6 Mower-Rake Combination benefits from the same production standards and quality controls as every other machine in the range.

Agronomic and Operational Fit

The 9GL-5.0/5.6 Mower-Rake Combination is designed for operations requiring 5.0m mow and 5.6m rake in single pass capability with 30–60 kW (40–80 HP) tractor power. Across Argentine agricultural regions, this covers:

• Buenos Aires Province: High‑rainfall improved pasture systems where 5,000mm cut / 5,600mm rake combination bale format suits local handling and storage infrastructure.
• Córdoba Province: Mixed cropping systems where 5.0m mow and 5.6m rake in single pass handling requirements align with the seasonal rotation of this region.
• Santa Fe and Entre Ríos: Intensive livestock and dairy systems where halving field passes and reducing per-hectare cost is a primary operational requirement.
• Patagonia and arid zones: Extensive operations where reliable, low‑maintenance equipment is essential due to limited service infrastructure.

Total Cost of Ownership

Purchase price is only the first cost. Annual maintenance on the 9GL-5.0/5.6 Mower-Rake Combination typically represents 2–4% of purchase price — a range that reflects the reduced maintenance requirements of the camless and axial‑flow design elements where applicable. Downtime cost during peak harvest is reduced by the blockage‑resistance feeding design. Residual value is supported by ISO‑certified build quality and verifiable manufacturer credentials that informed second‑hand buyers recognise.

Contact [email protected] for a 5‑year total cost of ownership comparison for the 9GL-5.0/5.6 Mower-Rake Combination versus alternatives you are evaluating. We provide this analysis for buyers who request it as part of the quotation process.

Seasonal Integration and Operating Calendar

The 9GL-5.0/5.6 Mower-Rake Combination's place in your annual operational calendar depends on its specific application. For primary hay and forage equipment, the peak use period is September through April in Argentina's agricultural zones. Pre‑season preparation in August — maintenance inspection, parts pre‑ordering, operator familiarisation — ensures the machine is ready when the season begins.

Off‑season storage should be in covered or semi‑covered conditions. Clean all crop debris from the machine before storage — accumulated organic material retains moisture and accelerates corrosion at contact points. Park with pick‑up in the raised position to relieve pressure on the tine carrier springs. Cover PTO shaft ends to prevent moisture and grit ingress into the shaft splines during storage.

Pre‑Purchase Qualification Checklist

Before placing an order for the 9GL-5.0/5.6 Mower-Rake Combination, confirm the following with your farming or operating team:

• Your tractor produces at least 30–60 kW (40–80 HP) at the PTO — confirm against your tractor's rated specification
• Your annual operational requirement for integrated mower-rake services justifies the capital investment at current prices
• Your storage and handling infrastructure is compatible with the bale format produced by this machine (5,000mm cut / 5,600mm rake combination)
• Your operating location has adequate service access — either via our Buenos Aires team or via acceptable road freight for parts supply
• Your seasonal calendar provides adequate operating time to achieve target return on investment from the machine

If any of these items cannot be confirmed, contact our team before ordering — we will help identify the correct machine or configuration for your situation.

Buyer Scenarios

The following scenarios represent common operational contexts for the 9GL-5.0/5.6 Mower-Rake Combination:

Scenario 1: Owner‑Operator Small Property

A 150–300 hectare owner‑operated mixed farm with one main tractor and a seasonal baling requirement. The 9GL-5.0/5.6 Mower-Rake Combination's integrated mower-rake capability covers the core baling needs of this operation. Its compatibility with 30–60 kW (40–80 HP) tractors matches the typical tractor available on this farm scale. Low‑maintenance design is valued by owner‑operators who service their own equipment.

Scenario 2: Agricultural Contractor

A contractor servicing multiple properties through the season needs reliable, versatile equipment. The 9GL-5.0/5.6 Mower-Rake Combination's 5.0m mow and 5.6m rake in single pass handling capability — covering the crop types found across the contractor's client base — reduces the number of machine configurations required. Consistent output quality supports the contractor's commercial relationships with clients who specify density or quality standards.

Scenario 3: Large Integrated Property

A large property running 500–2,000 hectares with multiple tractors and dedicated operators. The 9GL-5.0/5.6 Mower-Rake Combination fits into the operation's forage chain — halving field passes and reducing per-hectare cost — and its ISO‑certified quality and local parts support from Buenos Aires reduces operational risk relative to less‑credentialed alternatives.

Extended Frequently Asked Questions

Can the mowing and raking functions be used independently?

The 9GL‑5.0/5.6 is designed as an integrated combination machine — both functions operate simultaneously. If you need to mow without raking, or rake without mowing, separate dedicated machines from the Ever‑Power range (9GD‑2.5 mower, 9LH‑12 rake) are more appropriate.

What terrain gradient is the 9GL-5.0/5.6 suitable for?

The machine is rated for flat to moderately sloped terrain — typically up to approximately 15 degrees of cross‑slope. On steeper slopes, the combination machine's geometry creates windrow inconsistency that reduces the efficiency advantage over separate mowing and raking machines.

What documentation comes with the machine at delivery?

Each machine is delivered with: operator and maintenance manual (English language), warranty certificate, certificate of conformity, parts catalogue, and installation checklist. For export orders, the commercial invoice, certificate of origin, and phytosanitary certificate are provided with the shipping documentation.

How do I order spare parts?

Contact [email protected] with your machine serial number and the part number or description from the parts catalogue. We confirm availability, price, and dispatch time within one business day. Common consumables are stocked locally in Buenos Aires for same‑week dispatch.

Is the machine eligible for Argentine agricultural equipment subsidies or credits?

Contact Argentina's Secretaría de Agricultura, Ganadería y Pesca (SAGyP) or the Banco de la Nación Argentina agricultural lending programmes for current machinery subsidy and credit line eligibility. We provide the technical documentation and certificates of origin required for most application processes on request.

Can I inspect the machine at your Buenos Aires facility before purchase?

Yes. Contact [email protected] to arrange a visit to our Parque Industrial Pilar facility. In‑person inspection is available for buyers considering larger orders or those requiring specific configuration confirmation before order placement.

Manufactured to International Standards

Every component leaves a 32,000 m² ISO9001:2015 certified facility, processed through CNC laser cutting, robotic welding lines, and electrostatic coating for corrosion-resistant finish.
